NexFS

v1.3.0 — 375+ Tests Passing

NexFS is the Nexus sovereign filesystem — a flash-native, graph-structured storage layer implemented in Zig with zero dynamic allocation. It runs on everything from bare-metal microcontrollers with 64 KB RAM to multi-hundred-terabyte Homenodes. No libc. No OS required.

Objects exist in a directed graph — location is a relationship, not an identity.

Address Space (v4)

NexFS v4 uses u64 block addressing throughout. At 4 KB block size, a single volume addresses 64 ZB — enough for a Homenode with 352 TB of mixed NVMe + SAS storage, a 1,000-node Chapter at 352 PB, or planetwide mesh at exabyte-to-zettabyte scale over a 15+ year horizon.

Field	Width	Ceiling @ 4 KB blocks
BlockAddr	u64	64 ZB per volume
block_count (Superblock)	u64	64 ZB
bucket_id (BamEntry)	u32	4B buckets (~8 EB at Hydra bucket size)
data_count (Allocator)	u64	64 ZB
Inode.block_count	u64	64 ZB per file
InodeId	u32	4B inodes per volume (cross-node uses CAS CIDs)
Inode.size	u64	16 EB per file
device_size	u64	16 EB

BamEntry overhead: ~0.4% per TB. Negligible. Superblock at 256 bytes still fits in a single 512-byte minimum block with room for future mesh and sovereignty fields.

The Kenya Rule

NexFS holds to the doctrine that governs the entire Nexus stack: if a solar-powered phone in Mombasa with 4 hours of daily connectivity can't participate meaningfully, the protocol fails everywhere. The same CAS-DAG format runs on every tier, addressed by the same BLAKE3 hashes, deduplicating across machines that may never share a network.

Profile	Binary	DRAM	Flash	Kenya Rule
nexfs-core	~40 KB	8.5 KB	512 KB	Sensor / MCU
nexfs-sovereign	~120 KB	≤ 1 MB	8 MB	Phone / laptop
nexfs-mesh	~200 KB	≤ 4 MB	8 MB	Home box edge

The binary the server runs is the binary the sensor runs. Sovereignty is not a luxury good.

Architecture

NexFS is built from 18 composable modules. Each module is a self-contained compilation unit with no hidden state:

superblock ─── inode ─── dir ─── dir_ops ─── path ─── graph
    │              │                │
  format        file ── cow      alloc ─── bam
    │              │
checkpoint     journal ── cas ── cas_journal
    │                       │
  scrub          health   features     compress
                                         │
                           xattr ── lock ── watch

On-device layout (block-linear):

┌──────────────┬──────────────┬──────┬─────────────────┬───────────────┐
│ Superblock 0 │ Superblock 1 │ BAM  │  Inode Table    │  Data Blocks  │
│ (256B, dual) │ (256B, dual) │      │  (4 blocks)     │               │
└──────────────┴──────────────┴──────┴─────────────────┴───────────────┘
   Block 0         Block 1     Blk 2    Blocks 3-6        Block 7+

Core Format

Fixed-size, alignment-safe structures for deterministic flash access:

Structure	Size	Purpose
Superblock	256 bytes (dual + scattered)	Volume identity, format v5, generation counter, feature flags, mesh fields
Inode	128 bytes	File/directory metadata, inline extent, checksum
Extent	16 bytes	Contiguous block range (logical → physical mapping)
DirEntry	48 bytes + name + tag	Directory entry with edge type and optional tag
BAM Entry	16 bytes	Block Allocation Map — state, erase count, owner (u32 bucket_id)

Superblock Resilience: Dual + Scattered Replicas

NexFS writes superblocks at blocks 0 and 1 as primary and backup. v1.3.0 adds scattered superblock replicas — up to 16 additional copies spread deterministically across the data region. On mount, if blocks 0 and 1 are both corrupt, NexFS calculates all replica positions from volume geometry alone and recovers from the highest-generation valid replica.

Profile	Replicas	Convergence
Core	4 (2 scattered)	1 checkpoint
Sovereign	8 (6 scattered)	3 checkpoints
Mesh	10 (8 scattered)	4 checkpoints

Each checkpoint writes blocks 0+1 plus K=2 rotating scattered replicas. All replicas converge over ceil((N-2)/K) checkpoints. Replica positions are derived from volume geometry — no stored map, no chicken-and-egg.

Per-Inode Checksums

Every inode carries a checksum computed over all metadata fields. The hash algorithm is selectable per individual inode — not per-filesystem. A sensor logging temperature data can use XXH3 for speed, while a signing key stored on the same volume uses BLAKE3 for cryptographic integrity.

Hash	Enum	Output	Use Case
BLAKE3-256	0x00	256-bit	Default. CAS addressing, Merkle DAG, provenance chains
BLAKE3-128	0x01	128-bit (padded)	Constrained devices needing crypto guarantees
XXH3-64	0x02	64-bit (padded)	Ultra-fast integrity for high-throughput embedded

Graph-Native Directories

NexFS directories are not flat lists of names — they are typed edge sets in a directed graph. Every directory entry carries an explicit edge type that defines the relationship between parent and child:

Edge Type	Value	Semantics
primary	0x00	Normal parent-child ownership. GC follows these.
reference	0x01	Non-owning "also lives here" — like a symlink that doesn't break
pin	0x02	Anchor edge. Prevents garbage collection even if all other edges are removed
projection	0x03	Auto-generated. Smart folder / query result

Edge Tags

Each directory entry can carry an arbitrary tag (up to 63 bytes) — metadata attached to the relationship, not the file. Use cases:

• Capability tokens on mount edges
• Version labels on DAG edges
• Role annotations ("owner", "reviewer") on reference edges

RevMap: Reverse Edge Index

The RevMap is an in-memory reverse index built lazily by scanning the directory tree. It maps every inode to all edges pointing at it — enabling O(1) answers to "who references this file?" without a full tree walk.

• Orphan detection: revmap.isOrphan(inode_id) — zero incoming edges
• Edge queries: revmap.queryEdges(inode_id) — all parents and edge types
• GC safety: removeEdge() refuses to create orphans unless force=true
• Depth-limited scan: Recursion capped at 64 levels to prevent stack overflow from cycles

File Operations

Extent-based file I/O with seek support:

Operation	Function	Notes
Open	FileOps.open()	Returns handle with position tracking
Read	FileOps.read()	Extent-resolved block reads. Returns 0 at EOF.
Write	FileOps.write()	Allocates blocks via BAM, extends inode
Seek	FileOps.seek()	Absolute, relative, or from-end positioning
Truncate	truncateInode()	Shrink or extend. Frees released blocks.
Close	FileOps.close()	Releases handle state

Copy-on-Write Cloning

cloneInode() creates a deep copy of a file's extent tree. The clone gets its own inode with FLAG_COW set. Data blocks are physically copied (not shared), so the clone is fully independent. Maximum 64 extents per clone operation.

Subsystems

Checkpoint

Atomic metadata flush to persistent storage:

1. Seal all open allocation buckets
2. Flush the Block Allocation Map
3. Increment the superblock generation counter
4. Write both superblocks (primary + backup)
5. Write K=2 rotating scattered replicas (if REQ_SCATTERED_SB)
6. Sync to flash — errors propagate (not silently swallowed)

Write-Ahead Journal

Intent-logging journal for crash-safe multi-step operations:

begin() → recordIntent(addr, data) → commit() → recover()

Recovery semantics: entries in committed state represent writes that were already executed before commit() was called. The journal is cleared on recovery.

Integrity Scrub

Background integrity scanner that walks every allocated inode in the table:

• Validates inode checksums against stored hashes
• Counts total inodes scanned and checksum errors found
• Returns ScrubResult with error counts — zero errors means clean volume
• Available via C-FFI as nexfs_scrub()

Extended Attributes

Typed attribute slots on inodes (not POSIX xattr — purpose-built for Nexus capabilities):

Type	Value	Purpose
capability_perms	0x01	Capability permission bitfield (SPEC-051)
cas_cid	0x02	CAS content ID, 32 bytes
encryption_flags	0x03	Encryption configuration
provenance_hash	0x04	Provenance chain hash
custom	0xFF	Arbitrary key-value (63-byte key, 255-byte value)

Block Allocation

Bitmap-based allocator with bucket lifecycle tracking:

Bucket State	Value	Meaning
free	0x00	Available for allocation
writing	0x01	Currently being written to
full	0x02	Sealed, contains live data
evacuating	0x03	Being emptied by GC (Hydra phase)
parity	0x04	Erasure coding data (Hydra phase)

Additional Modules

Module	Purpose
Compress	ZSTD (1–22) + RLE compression with per-node/per-chunk level selection and double checksum (FLAG_COMPRESSED)
Lock	Advisory inode locking with table-based tracking
Watch	Inode change notification (create, modify, delete events)
Health	Flash health statistics from BAM erase counts
Path	Full path resolution with loadSafe() bounds checking

Volume Profiles

NexFS scales via the Baukasten (building-block) model — three profiles activate different module sets:

Profile	Storage Class	Footprint	Features
Core	0x00	~40 KB	Block I/O, inodes, BAM, checksums, scrub, per-bucket RLE block compression
Sovereign	0x01	~400 KB	+ CAS, CDC, DAG versioning, TimeWarp snapshots, ZSTD compression (1–22)
Mesh	0x02	~480 KB	+ Wire protocol, peer sync, gossip, ZSTD compression (1–22)

Compression (v1.1.0)

NexFS supports four compression granularity modes, selectable at format time:

Mode	Profile	Granularity	Use Case
per_bucket	Core	Per-block via BAM entry	IoT/satellite – RLE per block, radiation-tolerant
per_dag_node	Sovereign	Per-file via DAG metadata	File-level default algo+level
per_cas_chunk	Sovereign	Per-CAS-chunk	Chunk-level granularity
per_dag_and_chunk	Sovereign	DAG default + chunk override	ZSTD:2 on system, ZSTD:18 on archives – same volume

Double-checksum integrity (ZSTD only): XXH3-64 of compressed data is computed during the streaming compress pass (piped, zero extra cost) and verified before decompression. Bit flips are caught before ZSTD touches the data.

Per-bucket block compression operates at the file I/O layer. Each block's BAM entry carries comp_algo and comp_level. On write, the full block is compressed and stored with a 2-byte length prefix. On read, the block is decompressed before extracting the requested portion. Partial-block writes use read-modify-write to preserve existing data.

Feature Flags & Runtime Tuning (v1.3.0)

Two 32-bit bitmasks in the superblock control mount-time compatibility:

• required_features — unknown set bits prevent mounting (forward compatibility)
• optional_features — unknown set bits are safe to ignore

Required Flag	Bit	Effect
REQ_COMPRESSION	0	Block-level compression active
REQ_ZSTD	1	ZSTD compression (implies REQ_COMPRESSION)
REQ_DOUBLE_CHECKSUM	2	XXH3-64 secondary hash on compressed blocks
REQ_CAS_DEDUP	3	Content-addressable deduplication
REQ_SCATTERED_SB	6	Superblock scattered across volume

Optional Flag	Bit	Effect
OPT_RECOMPRESSION	0	Background recompression enabled
OPT_MESH_SYNC	1	Mesh synchronisation active
OPT_TIMEWARP	4	TimeWarp snapshot layer

Feature parameters at superblock offsets 0x64–0x68 provide scalar configuration for active features:

Param	Offset	Gate	Default (Sovereign)
sb_replica_count	0x64	REQ_SCATTERED_SB	8
sb_checkpoint_batch	0x65	REQ_SCATTERED_SB	2
recompress_target_algo	0x66	OPT_RECOMPRESSION	ZSTD (0x02)
recompress_target_level	0x67	OPT_RECOMPRESSION	3
recompress_free_floor	0x68	OPT_RECOMPRESSION	10%

All parameters are runtime-tunable via nexfs_tune() without unmounting.

COW Re-Compression (v1.3.0)

Background re-compression upgrades stored chunks to better algorithms without data risk. The filesystem provides the mechanism; policy (aging, scheduling, pacing) lives in the Nim Membrane daemon.

The invariant: never modify a committed block. Old data survives until new data is written and journaled.

1. Read chunk → decompress → verify BLAKE3 CID
2. Recompress with target algo/level
3. COW: allocate new block(s), write, journal, update CAS entry
4. Free old block(s)

Batch mode groups up to 32 chunks in a single journal transaction with full rollback support. A free-space floor (default 10%) prevents recompression from filling the volume — the guard is a crash-safety invariant, not optional policy.

Sovereign Extensions

When running with the Sovereign profile:

• Content-Addressable Store (CAS): Files addressed by BLAKE3 hash. Automatic deduplication. ZSTD compression with double-checksum integrity on put/get.
• Content-Defined Chunking (CDC): Large files split at content-determined boundaries. Small edits re-store only changed chunks.
• DAG Versioning: File history as a Merkle DAG. Efficient branching, merging, and cryptographic history verification.
• TimeWarp Snapshots: Instant O(1) filesystem snapshots via copy-on-write DAG nodes.

C FFI

NexFS exposes a complete C-compatible API for integration with the Rumpk kernel and other system components:

// Lifecycle
nexfs_format(cfg)                    // Format a flash volume
nexfs_mount(cfg)                     // Mount (dual-SB failover)
nexfs_unmount()                      // Unmount
nexfs_is_mounted()                   // Check mount status
nexfs_sync()                         // Flush pending writes
nexfs_checkpoint()                   // Atomic metadata checkpoint

// File operations
nexfs_create(path, mode)             // Create file, returns inode ID
nexfs_read(path, buf, len)           // Read file data
nexfs_write(path, buf, len)          // Write file data
nexfs_delete(path)                   // Delete file
nexfs_truncate(path, new_size)       // Truncate/extend file
nexfs_rename(old_path, new_path)     // Move/rename
nexfs_clone(src_path, dst_path)      // CoW deep copy
nexfs_shred(path)                    // Secure erase (overwrite + flash erase)

// Directory operations
nexfs_mkdir(path, mode)              // Create directory
nexfs_rmdir(path)                    // Remove empty directory

// System
nexfs_scrub(result)                  // Integrity scan
nexfs_health(stats)                  // Flash health statistics
nexfs_lock(inode_id)                 // Advisory lock (non-blocking)
nexfs_unlock(inode_id)               // Release lock

// Recompression
nexfs_recompress(cid, algo, level)     // COW recompress single chunk
nexfs_recompress_batch_begin()          // Start batch transaction
nexfs_recompress_enqueue(cid, a, l)     // Enqueue chunk
nexfs_recompress_batch_commit()         // Commit all + free old blocks
nexfs_recompress_batch_rollback()       // Undo all

// Tuning
nexfs_tune(param, value)                // Runtime parameter adjustment

All functions return 0 on success or a negative error code. Read/write return byte counts.

Wire Protocol

For networked volumes (Mesh profile), NexFS uses a wire protocol over UTCP:

Message	Purpose
BLOCK_WANT	Request a block by hash
BLOCK_PUT	Deliver a block
DAG_SYNC	Synchronize DAG heads between peers

Design Principles

Principle	Implementation
Zero dynamic allocation	All buffers caller-provided. No malloc, no heap.
No-std compatible	Zig with no libc. Runs on bare metal.
Flash-native	Designed for NOR/NAND characteristics. No FTL assumption.
Graph-first	Directories are edge sets, not flat lists.
Integrity by default	Per-inode checksums. Dual superblock. Scrub.
Fail-safe writes	Checkpoint propagates errors. Journal for multi-step ops.

Comparison

For an honest, detailed comparison of NexFS against ext4, F2FS, XFS, ZFS, Btrfs, bcachefs, and HAMMER2, see NexFS vs. The Field.

License

LSL-1.0 (Libertaria Sovereign License)
